How to Install Copper Supply Lines: A Step-by-Step Guide

Ensure clean joints, secure fittings, and decades of leak-free plumbing performance.

By Medha deb

Created on Sep 26, 2025

Ensure clean joints, secure fittings, and decades of leak-free plumbing performance.

How to Run Copper Supply Lines

Adding or updating water supply lines with copper pipe is a classic plumbing upgrade: it’s durable, attractive, and delivers decades of service if installed properly. This comprehensive guide explains the steps, tools, materials, and safety tips needed to run copper supply lines, whether you’re renovating a bathroom, kitchen, laundry area, or replacing old piping.

Why Choose Copper for Supply Lines?

Copper pipe has earned its reputation through decades of proven reliability in both residential and commercial plumbing. Its key benefits include:

Corrosion resistance: Copper naturally resists most types of pipe corrosion, making it dependable for water supply.
Durability: Properly installed, copper piping can easily last 50+ years.
High-pressure tolerance: It handles high-pressure systems and both hot and cold water distribution.
Environmental safety: Copper is non-toxic and doesn’t leach chemicals into water.
Versatility: Available in rigid and flexible forms, copper adapts to almost any project.

Before You Begin: Planning Your Copper Pipe Installation

Thorough preparation is key to successful plumbing. Take the following steps before you start any pipe work:

Draw a plan of the required water lines, noting all branches, fixtures, and shutoff valves.
Locate all existing lines, considering where new pipes will tie in.
Check if permits or inspections are needed in your area.
Determine if you’ll need to transition to or from other materials (PVC, PEX, galvanized steel) and select the appropriate adapters.

Tip: Plan for the most direct routing possible to minimize pressure loss and the number of joints, both of which can become potential leak points.

Tools and Materials Needed

You’ll save time if you gather all necessary supplies before starting. Here’s a checklist for most copper pipe installations:

Type M or L copper pipe (Type L is thicker and used for longer-lasting installations)
Pipe cutter, hacksaw, or tubing cutter
Pipe cleaning brush or sandpaper
Fitting brush
Flux and flux brush
Lead-free solder
Propane torch (with striker/lighter, not matches)
Pipe fittings (elbows, tees, adapters, couplings, etc.)
Pipe supports and clamps
Fire-resistant cloth or heat shield
Measuring tape and marker
Safety gear: goggles, gloves, fire extinguisher nearby

Steps for Running Copper Supply Lines

1. Shut Off Water Supply

Always turn off the main water supply before opening or cutting any pipes. Drain existing supply lines by opening faucets at the lowest and highest points in the system to remove residual water.

2. Measure and Plan Pipe Runs

Take precise measurements between connection points, accounting for fitting lengths.
Cut copper pipes to length using a pipe or tubing cutter: score the pipe all the way around, then tighten the cutter incrementally until the tube snaps cleanly.
For multiple runs, cut and dry-fit all sections ahead of time for efficiency.

3. Prepare Pipe Ends and Fittings

Deburr both the inside and outside of cut pipe ends: use a reamer or deburring tool to remove sharp edges that can damage fittings and cause leaks.
Clean pipe ends and the inside of fittings with a wire brush or emery cloth to remove oxidation and debris.

A properly cleaned surface is essential: even slight oxidation can prevent solder from bonding, leading to leaks.

4. Dry-Fit Everything

Assemble all pipe sections and fittings without flux or solder to confirm layout and fit.
Mark pipe and fitting orientation with a marker to ensure accurate reassembly during soldering.

5. Apply Flux and Assemble

Use a flux brush to apply a thin, even layer of certified plumbing flux to the outside of the pipe ends and inside the fitting sockets.
Slide each fitting fully onto the pipe. Wipe away excess flux that squeezes out.

Flux removes oxidation during heating and helps solder flow into the joint, forming a long-lasting seal.

6. Solder (Sweat) the Joints

Protect nearby surfaces with a fire-resistant cloth or heat shield.
Ignite the propane torch and adjust to a small, steady blue flame.
Heat the fitting joint evenly, moving the flame around until the flux bubbles and sizzles.
Touch the solder to the joint—not the flame. When hot enough, solder will melt and be drawn by capillary action around the entire joint.
Remove the flame and continue feeding a small amount of solder to ensure total coverage.
Let the joint cool naturally. Wipe away any excess flux with a damp cloth.

7. Secure the Pipes

Attach pipes to structural members using pipe clamps or supports at recommended intervals (usually every 6–8 feet for horizontal runs, as close as possible to every new fitting or valve).
Allow for thermal expansion by leaving a small gap between the pipe and the wall or support bracket.
Ensure no pipe is in direct contact with dissimilar metals (which can accelerate corrosion); use dielectric unions if joining to steel or galvanized piping.

8. Pressure-Test and Check for Leaks

Once all joints are cool and secure, slowly turn the main water supply back on.
Check each joint carefully for leaks. Even tiny drips should be repaired immediately.
Tighten or re-make failed joints by reheating and applying more solder if necessary.

Special Considerations for Routing Copper Pipe

Different situations require slightly different approaches to routing and supporting copper pipe:

Through Floors or Walls: Drill holes slightly larger than the pipe’s diameter to allow for movement.
In concrete or masonry, use a plastic sleeve or wrap with pipe insulation to protect the copper from corrosion caused by concrete contact.
Bends & Corners: Use copper elbows (45° or 90°) or gentle bends if using flexible Type L pipe for fewer fittings and less turbulence.
Keep pipes at least 1 inch away from electrical wires and use grommets or isolation pads to prevent abrasion.

Alternative Connection Methods

Besides traditional soldering, other methods can be used for connecting copper pipes, especially in situations where open flames are unsafe:

Connection Type	Pros	Cons
Compression Fittings	Quick and secure, good for valve or fixture connections and repairs.	May loosen over time under vibration; not as permanent as solder.
Push-Fit (Press) Fittings	No tools or heat required, easy for DIY, fast installation.	Expensive; long-term durability slightly less proven than soldered joints.
Brazing	Stronger, suitable for high-pressure/temperature applications.	Requires higher heat, more skill, and special rods.

Joining Copper to Other Materials

Most remodels encounter a need to transition between copper and other pipe types. Always use manufacturer-recommended adapters; don’t force a mismatched thread or use makeshift couplings. Typical transitions include:

Copper to PEX: Use a brass or copper crimp adapter specifically designed for copper-to-PEX connections.
Copper to PVC/CPVC: Use a threaded adapter and transition union (never glue copper directly to plastic).
Copper to galvanized steel: Use a dielectric union to prevent corrosion at the connection point.

Common Mistakes and Troubleshooting

Insufficient cleaning: Dirty pipes or fittings prevent proper solder flow, resulting in leaks.
Overheating the joint: Excessive heat can cause flux to burn and block solder flow, or damage fittings.
Uneven solder: Solder should follow the joint circumference smoothly. Lumpy or incomplete rings may mean the joint needs to be remade.
Pipes not properly supported: Unsupported runs sag, which can increase the risk of leaks and damage.
Forgot thermal expansion: Allow slight movement to avoid stress cracks from temperature fluctuations.

Safety Tips for Working with Copper Pipes

Always wear safety goggles and gloves to protect against metal shards and hot solder.
Keep a fire extinguisher within reach whenever using a propane torch.
Work in well-ventilated areas, and use a spark shield where possible to prevent accidental fires.
Never solder a pipe that could contain water, as steam can cause dangerous bursts or failed joints.
Dispose of any cut-off or used pipe sections responsibly, as copper has value for recycling.

Maintenance and Longevity

Once installed, copper piping requires little maintenance other than periodic inspection. Look for signs of greenish corrosion or unexplained moisture, particularly at joints and connections. Promptly address any leaks or damage. With proper care, your new copper supply lines can outlast the fixtures they serve.

Frequently Asked Questions (FAQs)

How do I know which type of copper pipe to use—Type M or Type L?

Type L copper pipe is thicker and has a longer service life, making it preferred for most residential supply lines. Type M is thinner and less expensive, often used for non-pressurized applications but is not always permitted for domestic water.

Can I run copper water lines through concrete?

Yes, but copper pipes must be sleeved or wrapped to prevent corrosion from contact with concrete. Use plastic sleeves and avoid direct burial in corrosive environments.

Should I solder or use push-fit fittings?

Soldered joints offer a permanent, reliable seal and remain the standard for most applications. Push-fit fittings are easier and faster, worthwhile for repairs or in places where using a torch is hazardous, though they cost more and have a shorter track record.

How do I fix a leak in a copper pipe?

Shut off the water, cut out the damaged section with a pipe cutter, and replace with a new piece and appropriate fittings (solder, compression, or push-fit). Ensure all joints are clean and properly assembled to prevent repeated leaks.

How can I tell if my solder joint is good?

A quality solder joint will display a smooth, continuous ring of solder around the entire circumference. There should be no visible gaps, lumps, or pinholes. Test the joint under pressure for leaks before closing up walls or completing other stages of renovation.

Final Thoughts

Running new copper supply lines is a manageable DIY project for careful homeowners with the right tools and an understanding of basic plumbing techniques. Take your time at each step to ensure clean, secure, and properly routed pipes. If ever in doubt—or if local codes require—consult a licensed plumber for assistance.
